Description
Description
Digital multimeter is used to diagnose and detect faulty electrical components. Used in the automotive, electrical and installation industries.
Characteristic
- DATA HOLD keeps the currently measured value on the display
- LIVE – cable phase measurement / detects AC current in the cable
- multimeter measures DC voltage up to 600 V and AC voltage up to 600 V, DC current up to 10 A and resistance up to 2 MΩ, performs diode and continuity tests and battery tests with 1,5 / 9 V
- large LCD screen with blue backlighting, enables to display and read 1999 counts even in darkness
- rubber casing cover protects against mechanical damage
- comfortable, ergonomic, compact shape allows comfortable, single-hand operation
- powered by 2×1,5 V AAA batteries, longer battery life thanks to Auto Power Off
- a stand on the back of the body enables to position the device for better visibility of the displayed data, special holders for attaching cables and a bracket for hanging the meter on the wall
- test leads included.
Technical data
| Additional information | BATERY TEST 1,5 / 9V |
|---|---|
| DATA HOLD | YES |
| I DC [A] | 10 |
| Quantity in package | 1 |
| R [Ω] | 2M |
| U AC [V] | 45 |
| U DC [V] | 600 |
